Steel pallets are an optimal solution in logistics, warehousing, and industrial manufacturing thanks to their high durability, flexibility, and effective reusability. Choosing a reliable steel pallet manufacturer ensures greater peace of mind when it comes to transporting and storing goods.
Features
Steel pallets are primarily made of steel and used for supporting, transporting, and storing goods in warehouses, factories, or throughout logistics operations. They are often produced using sheet metal stamping techniques to ensure precision and consistency during mass production.
Compared to wooden or plastic pallets, metal pallets offer greater durability and load-bearing capacity, making them suitable for harsh environments involving humidity, temperature changes, or pest exposure. Therefore, heavy duty steel pallets are often the preferred choice in heavy industry or environments requiring strict storage standards.
Technical Specifications
Load Capacity Design
To select the right product for your needs, analyze the following load capacities:
- Static Load: The maximum load a pallet can bear when not in motion, usually ranging from 1,500 to 5,000 kg.
- Dynamic Load: The maximum load a pallet can bear while being moved by a forklift, typically from 1,000 to 2,500 kg.
- Racking Load: The maximum load a metal pallet can withstand when placed in a racking system. This depends on the racking design, the structure of the pallet, and the type of goods stored, and must be carefully evaluated.
Standard Dimensions
Depending on the application, type of goods, and region, metal pallet dimensions vary.
- Australia:
The standard size is 1165mm x 1165mm (45.9″ x 45.9″), known as ISO 1A or the industry standard, compatible with RACE containers used in Australian rail logistics. Export pallets are often 1100mm x 1100mm, aligning better with international container dimensions. - United States:
The most common pallet size is 1219mm x 1016mm (48″ x 40″), known as the GMA pallet (Grocery Manufacturers Association), widely used in retail, warehousing, and food distribution. GMA pallets are optimized for racking systems in North America and accepted by many global supply chains. - Canada:
Canada mostly uses the 1219mm x 1016mm (48″ x 40″) standard like the U.S. In certain industries such as automotive or cross-border logistics, block pallets or custom sizes may be used. Canadian steel pallets are built for durability in cold weather, with materials that can handle temperature fluctuations. - Europe:
The most commonly used size is 1200mm x 800mm (47.2″ x 31.5″), known as the EUR or Euro pallet (EPAL 1), standardized for logistics across the EU under UIC and EPAL regulations. For heavier loads, 1200mm x 1000mm (47.2″ x 39.4″) is also used, especially in the UK and for export logistics. Steel pallets manufactured in these sizes are ideal for European racking systems. - Japan:
The standard size is 1100mm x 1100mm (43.3″ x 43.3″), recognized by the Japanese Industrial Standards (JIS) and optimized for local warehouse layouts and forklift compatibility. For international exports, Japanese companies may also adopt 1200mm x 1000mm pallets to meet ISO or Western shipping container standards.
Materials
Common materials used by steel pallet manufacturers include carbon steel or stainless steel, typically in thicknesses from 1.2 to 2.0 mm.
Flexibility and Safety
Opt for metal pallets with rounded edges to ensure user safety and protect goods during handling and storage.
Also, consider stackable or disassemblable models to save space when they are not in use. High flexibility with forklifts, conveyors, and industrial racking systems is also recommended.
Common Types of Steel Pallets
Heavy duty steel pallets come in various designs to meet diverse industrial needs:
|
Type |
Structure | Advantages | Disadvantages |
Applications |
| Hot-dip Galvanized steel pallet | Fully hot-dip galvanized | Excellent corrosion resistance, durable, non-peeling zinc coating | High cost | Outdoor environments, coastal areas, cold storage. |
| Powder-coated steel pallet | Powder-coated surface | Aesthetic variety, easy to clean, dust-resistant | Prone to scratches from strong impacts | Food factories, garment plants, indoor warehouses. |
| Galvanized steel pallet | Electrically galvanized surface | Affordable, good rust resistance in dry environments | Not suitable for humid or harsh environments | Dry warehouses, light industry zones. |
| Oil-painted steel pallet | Regular oil-painted surface | Low cost, easy to fabricate | Peels easily, hard to clean, less durable | Short-term projects, local transport. |
Choosing a Reliable Steel Pallet Manufacturer
When selecting a trusted steel pallet manufacturer, consider the following:
- Production Experience and Capability: Evaluate whether the manufacturer is a reputable steel fabricator with experience in pallet production, custom metalwork, and large-scale industrial fabrication projects. A capable steel fabricator should possess modern equipment, skilled workers, and deep technical knowledge.
- Raw Material Quality: Prioritize suppliers with verifiable material certifications and reputable sources.
- Custom Design Capability: Choose a manufacturer capable of customizing pallet size, load capacity, and features based on your needs.
- Customer Feedback: Refer to previous clients’ reviews and feedback on their service and product quality.
Newinds is ready to deliver custom-made heavy duty steel pallets for any project size or geographic location. Our versatile services include:
- Laser Cutting
- Forming & Punching
- Stamping & Folding
- Bending & Machining
- Welding & Finishing
We also offer value-added services such as sourcing castings, plastics, rubber, and other machine parts.
If you’re looking for a high-quality steel pallet manufacturer with deep industry expertise and competitive pricing, we would be delighted to explore how we can fulfill your needs.
